Speaker Alchimist 2 Way AS-615e: Exceptional Sound Quality
The Speaker Alchimist 2 Way AS-615e is a remarkable speaker designed to deliver exceptional sound quality. It incorporates cutting-edge features and technologies, ensuring an incredible audio experience.
Key Features:
- Edge-Enhanced Steel Frame: The speaker is built with an edge-enhanced steel frame, providing added structural strength for durability and enhanced performance.
- Black Anodized Voice Coil Former: The black anodized voice coil former contributes to superior heat dissipation, enabling the speaker to handle high power levels without distortion.
- Linear Double-Roll Surround: Featuring a linear double-roll surround, the AS-615e offers precise cone movement, resulting in accurate and detailed sound reproduction.
- FEA-Designed High-Efficiency Motor: The complex FEA-designed high-efficiency motor ensures optimum performance and efficiency, delivering powerful and dynamic audio.
- Rigid Poly Mica-Coated Cone: The rigid poly mica-coated cone of the AS-615e is designed to optimize sound reproduction, providing clear and balanced audio across a wide frequency range.
- Rear Dampened Hybrid Silk Dome Tweeter: The AS-615e speaker incorporates a rear dampened hybrid silk dome tweeter, extending the frequency response and reproducing high frequencies with clarity and precision.
- High-Quality Mounting Hardware: To facilitate easy installation, the AS-615e comes with high-quality mounting hardware, ensuring a secure and stable mounting for effortless setup.
With its exceptional build quality, advanced technologies, and precise engineering, the Speaker Alchimist 2 Way AS-615e sets a new standard for audio performance. Whether used in a home audio setup or a professional sound system, the AS-615e delivers an immersive and captivating listening experience.
Details
SPECIFICATIONS:
- Crossover Type: 2nd order Linkwitz-Riley
- DC Resistance (Re): 2.3 ohms
- Filter Type: HP / LP
- System Frequency (Fs) Response: 60-20k Hz
- XO Frequency: 3.5kHz HP / LP
- Slope (Octave): -12 dB
- Tweeter Voice Coil Diameter: 25 mm
- Midrange Voice Coil Diameter: 35 mm
FEATURES
- Edge-enhanced steel frame for added structural strength
- Black anodized voice coil former for superior heat dissipation
- Linear double-roll surround for precision cone movement
- Complex FEA-designed high-efficiency motor
- Rigid poly mica-coated cone for optimized sound reproduction
- Rear dampened hybrid silk dome tweeter for extended frequency response
- High-quality mounting hardware included
IN THE BOX
- PNW-65CS2
- Manual
- Warranty
DIMENSIONS
- Overall Diameter (w/o Grille): 6.5 in / 166 mm
- Cut Out Diameter: 5.59 in / 142 mm
- Mounting Depth: 2.36 in / 60 mm
- Mounting Height (w/o Grille): 0.20 in / 5.2 mm
- Mounting Height (w/ Grille): 0.86 in / 22 mm
- Motor Diameter (w/ Cover): 4.6 in / 117 mm
- Grille Overall Diameter: 7.05 in / 179 mm
DIMENSIONS FOR TWEETER
- Overall Diameter: 2.13 in / 54 mm
- Cut Out Diameter: 1.85 in / 47 mm
- Mounting Depth: 0.63 in / 16 mm
