Digital Signal Processing

ALCHIMIST AD1C-800

Date of Manufacture: April 21, 2025

DSP Alchimist AD1C-800 Class D DSP Mono RMS 600W Amplifier for Excellent Car Audio

ALCHIMIST AD1C-800
DSP Alchimist AD1C-600 Class D Car Amplifier

Description

  • This is a 1-channel mono amplifier with a maximum output power of 800W at 1 ohm impedance. Thanks to advanced DSP (Digital Signal Processing) technology, this product can process the audio signal digitally with high accuracy, significantly improving the sound quality.
  • Technical Specifications:
    • Frequency Response: 17Hz - 180Hz
    • Signal-to-Noise Ratio: > 90dB
    • Total Harmonic Distortion: < 0.05%
  • Features:
    • Wide frequency range ensures deep and powerful bass
    • High signal-to-noise ratio provides clear and detailed sound
    • Compact design and lightweight (2kg) for easy installation in the limited space of a car
    • Low distortion for an exceptional audio experience without interference or distortion
  • Ideal for: Subwoofer speakers
DSP Alchimist AD1C-600 Class D Amplifier for Excellent Car Audio
DSP Alchimist AD1C-600 Digital Signal Processing Class D
DSP Alchimist AD1C-600 1 Channel Class D fof Sub Woffer

Details

SpecificationValue
Output Power (4 ohm)170W x 1CH
Output Power (2 ohm)350W x 1CH
Output Power (1 ohm)600W x 1CH
Frequency Response17Hz - 180Hz (-3 dB)
Signal-to-Noise Ratio> 90 dB
Sensitivity6V - 0.1V
Total Harmonic Distortion< 0.05%
Dimensions223 x 130 x 50 mm
Product Weight2 kg
